STBV45DT-AP
> 70.000 pcs in our german Stock
| HIGH VOLTAGE FAST-SWITCHING NPN POWER TRANSISTOR |
|---|
| VCBO 700V | VCEO 400V | Ic 0,75A | Ptot 0,95W |
| Manufacturer: STMicroelectronics |
| Package: TO-92 AMMOPACK |
| The STBV45DT-AP is the MJE13002A in TO-92 packages |
|---|
| It can replace a lot of other high-voltage transistors (e.g. 13001, 13002, 13003) in TO-92 of manufactures (like ON,TI, FSC etc.) |
Request Quote
Please complete all required fields with your contact information. Click "SUBMIT RFQ" we will contact you shortly by email. Or Email us: request@pargos.de
Technical information
The device is manufactured using High Voltage Multi Epitaxial Planar technology for high switching speeds and high voltage capability. It uses a Cellular Emitter structure with planar edge termination to enhance switching speeds while maintaining the wide RBSOA. The STBV series is designed for use in Compact Fluorescent Lamps.
• HIGH VOLTAGE CAPABILITY
• LOW SPREAD OF DYNAMIC PARAMETERS
• MINIMUM LOT-TO-LOT SPREAD FOR RELIABLE OPERATION
• VERY HIGH SWITCHING SPEED
APPLICATIONS:
• COMPACT FLUORESCENT LAMPS (CFLS)
NOT PULLED - NOT USED - NOT REFURBISHED - NOT SOLDERED - NOT RE-MARKED - NOT FAKED
EXCLUSIVELY NEW OLD STOCK (NOS)
